1. Fault detection and alarm functions, easy to use and maintenance
2. The running status can be programmed and controlled with the built-in keyboard on the main board
3. Mechanical anti-pinch function. If the gate meets resistance in the reset process, motors will stop working automatically within the prescribed time and reset again after the default delay (till fully reset)
4. Anti-breakthrough function. The gate is locked automatically until opening signal received
5. Support infrared photocell for anti-pinch and reset function
6. Automatic reset function. Should the user fail to pass within the prescribed time (default time is 5 seconds), the system will cancel the authority of the current user automatically
7. Gate can be set as normally open or normally closed
8. Can be used with variety of card readers: IC / ID card readers, bar codes, fingerprints, etc. (Access controller needed)
9. Direction can be set as single-direction or bi-direction
10. LED direction indicator
11. Gate auto opens when power off and auto close when power on
12. Alarm function, in case of illegal intrusion and reverse intrusion, etc.
Product Specs
Power supply
AC220±10%V 50Hz/AC110±10% 60Hz
Motor voltage
DC 24V
Access device input voltage
Dry contact or 12V electrical level signal or > 100ms 12V impulse signal, driving current > 10mA
Direction
Can be set as single or double
Max flow rate
25 to 30 person per minute
Flap openning/closing time
1s
Flap lenght
270mm
Flap material
Acrylic or foam
Working temperature
-20°C~+60°C
Working humidity
0~95%RH
Application
Indoor/ outdoor with tent
Product size
Case reference
Related products
Our Company
Shenzhen Sinomatic Technology Co., Limited always focus on the manufacturing of access control turnstile and barrier for high security with the customers' encouragements and supports. Main products includes pedestrian control turnstiles, parking barriers and parking locks, road blockers and road bollards etc. Products has been exported to all over the world, favored by the majority of the customers. High quality and good faith for customers is our pricinple and this is also our biggest motivation.
